Description
Technical Specifications
| Description | Advantage |
|---|---|
| 1300X2500X200mm working area | Steel gantry, big and thick square tube, heavy structure for heavy use |
| 9 KW Air Cooled Spindle | Best quality, more stable performance |
| 11 KW Imported DELTA Inverter | Best quality, more stable performance |
| CNC Controller | With USB Interface, Easier to operate and space saving with remote handler. |
| Servo motor and drivers | 4 sets in total, double motors for Y axis, LEADSHINE/WEIHONG Brand |
| #30, Linear Guide way for X,Y,Z axis | Improve high precision, smooth transmission, fast speed, low noise & It has 10 times longer life |
| Helical Rack Gears for X,Y Axis | German imported big loading capacity, very powerful for machine, long lifetime |
| Ball screw for Z Axis | Accurate precision, smooth transmission |
| Vacuum Table | Bakelite Vacuum table for strong holding of work pieces with 5.5Kw Vacuum pump |
| Manual Lubrication System | Manual Lubrication system helps lubricate the rail way, maintaining machine |
| Japan OMRON limit switch for X,Y,Z axis | Help each axis go back to working home position |
| Soft Limit Switch | Help protect machine axis |
| Type 3 Software | Professional software for 3 axis work |
| Description | CNC ROUTER |
|---|---|
| X,Y,Z Working Area | 1300 x 2500 x 200mm |
| Table Surface | Bakelite vacuum table |
| X,Y, Structure | Rack & Pinion Drive, Rail Linear Bearings |
| Z Structure | Ball Screw, Rail Linear Bearings |
| Max. Working Speed |
60 mtrs/Min |
| Spindle Type | 9kw AIR COOLED SPINDLE With ISO Adopters |
| Spindle Speed | 0-24000 RPM |
| Drive System (with Gear Speed Reducer) | LEADSHINE / WEIHONG Servo System |
| Working Voltage | AC4 15V/50, 3PH |
| Command Language | G- Code |
| Operating System | NK 260 Weihong |
| Vacuum Pump | 5.5 KW AIR COOLED |
| Software Compatibility | Type 3 Software, Option: Art cam Pro |
| Saw Unit Motor |
7.5 KW |
| Scoring Unit Motor | 1.5 KW |
| Saw Blade Maximum Cutting thickness | 50 mm |
