Description
TECHNICAL SPECIFICATIONS
| DESCRIPTION | RC-1000 | C-1000 |
|---|---|---|
| Working width |
40-1000mm |
40-1000mm |
| Max Working thickness |
110mm |
110mm |
| Working Length |
≥600mm |
≥600mm |
| No.1 Sand Belt Speed |
22mtr/s |
18mtr/s |
| No. 2 Sanding Belt Speed |
— |
22mtr/s |
| Feed Speed |
5-25m./min |
5-25m./min |
| Size Of Sand Belt (wxp) |
1030x2200mm |
1030x2200mm |
| First Head Motor Power |
20 kw |
20 kw |
| Second Head Motor Power |
— |
22kw |
| Calleboration Sanding Head Roller Dia |
— |
240mm |
| Combination Head Roller Dia |
210 |
210 |
| Feed Motor |
3hp |
3hp |
| Table Hoist Motor |
0.5hp |
0.5hp |
| Working Air Pressure |
6-8 kg/cm² |
6-8 kg/cm² |
| Volume of Dust Collector |
6000m3/m |
9000m3/m |
| Consumption of Compressed Air |
0.1m3/mm |
0.1m3/mm |
| Net Weight (APPROX.) |
3600kgs |
4200kgs |
