Description
TECHNICAL SPECIFICATIONS
| DESCRIPTION | C-630 | RC-630 |
|---|---|---|
| Working width |
40-630mm |
40-630mm |
| Max Working thickness |
110mm |
110mm |
| Working Length |
≥600mm |
≥600mm |
| No.1 Sand Belt Speed |
22mtr/s |
18mtr/s |
| No. 2 Sanding Belt Speed |
— |
22mtr/s |
| Feed Speed |
5-25m./min |
5-25m./min |
| Size Of Sand Belt (wxp) |
630x2200mm |
630x2200mm |
| First Head Motor Power |
7.5kw |
7.5kw |
| Second Head Motor Power |
— |
10kw |
| Feed Motor |
2hp |
2hp |
| Table Hoist Motor |
0.5hp |
0.5hp |
| Working Air Pressure |
6-8 kg/cm² |
6-8 kg/cm² |
| Consumption of Compressed Air |
0.1m³/mm |
0.1m³/mm |
| Net Weight (APPROX.) |
2200kgs |
2700kgs |
